Abrasive Blasting Equipment | EcoQuip 2 EQ400t Elite

Name: Abrasive Blasting Equipment | EcoQuip 2 EQ400t Elite
Brand: Graco Australia

Supplier: Graco Australia

Graco's largest self-contained abrasive blasting trailer complete with integrated blaster and diesel compressor.

16 Recent ViewsIn Stock

Largest towable abrasive blasting trailer with option of integrated compressor

The EcoQuip 2 EQ400t is designed for the toughest high-production projects and comes with two compressor options. Select a trailer with no compressor, or one with a Tier 4f compressor with 425 CFM @ 175 PSI.

Features and Benefits

Comes with the option to include the Tier 4f compressor (425 CFM @ 175 PSI)
Redesigned controls for easier operation
Abrasive meter and MediaTrak for easy monitoring of media consumption
Blast hose, electric or pneumatic blast controls and nozzle sold separately

Vapor Abrasive Blasting: A cleaner, easier path to profitable results

Generates less dust – 92 percent less airborne dust than dry blasting
Uses less water than traditional water-based wet blasting
Optimizes air, water and media ratio – resulting in a fine mist with a blast that is powerful, but with less dust
Uses less media than wet blasting, so clean up is minimal* and you save on media costs

EcoQuip 2 EQ400T Elite
Operating Temperature	1.6° - 43.3° C
Blast Hose Size	31.75 mm ID
Abrasive Capacity*	400 kg
Pressure Pot Volume	184 liters
Water Tank Volume	492 liters
Tier 3
Maximum Working Pressure	8.61 bar, 0.86 MPa
Dry Weight	2721 kg
Wet Weight*	3628 kg
Air Capacity	10.6 m^3/min
Tier 4
Maximum Working Pressure	12.1 bar, 1.21 MPa
Dry Weight	3356 kg
Wet Weight*	4263 kg
Air Capacity	12 m^3/min
* Abrasive capacity and wet weight was found using 80 grit garnet. Using coarser media or less dense media will decrease weight.
Trailer Connections
Hitch Size	3 in. Lunette Ring (Pintel Eye)
Electrical Connector	7–way Flat Pin
Sound Data**
Sound Pressure Level	133 dB(A)
Sound Power Level	139 dB(A)
Instantaneous Sound Pressure Level	131 dB(C)
** All readings were taken at the maximum system blast pressure 150 psi (10.3 bar, 1.03 MPa) from the operator position. The abrasive used was garnet and the substrate was steel. Tested in accordance with ISO 9614-2.
