Barko 240B Tracked Harvester

Barko 240B Tracked Harvester is a high-performance 22.75-ton class forestry tractor engineered for severe slope handling and high-volume logging.

Receive 1-3 days from order

Feature / System	Details & Technical Specifications
Distributor (AU)	Colbrook Industries
Manufacturer	Barko Hydraulics
Product Category	Tracked Forestry Harvester / Harvester Tractor
Engine	225 HP (168 kW) Cummins QSB6.7, Tier 4 Final with SCR aftertreatment
Cooling System	Heavy-duty extreme cooling package with 36 in (914 mm) auto-reversing fan
Operating Weight	Approx. 45,500 lbs (20,639 kg) without attachment
Undercarriage & Pitch	Heavy-duty D5 undercarriage with 7.5 in (190 mm) chain pitch
Track Shoes & Width	600 mm pads (Overall Width: 9 ft 4 in / 284 cm) or optional 700 mm pads
Ground Clearance	26.2 in (66.5 cm)
Ground Pressure	7.63 psi (with 600 mm pads) / 6.54 psi (with 700 mm pads)
Drawbar Pull / Tractive	Superior drawbar pull ratio of > 1.3 to 1; Max Tractive Effort: 65,833 lbf (298.6 kN)
Hydraulic System	Load-sensing main pump operating at 4,500 psi (310 bar) + dedicated secondary attachment pump
Control System	Parker IQAN electrohydraulic system with IQAN-MD4 cab display and customizable profile settings
Swing System & Torque	Continuous rotation dual swing drive; 50,787 ft-lbf (68,858 Nm) swing torque; 53.5 in (1,359 mm) OD bearing
Boom Reach & Capacity	21 ft 2 in (645 cm) max reach; Front lift capacity up to 22,450 lbs (10,181 kg) at 10 ft radius
Cab Design & Service	Patent-pending forward-sliding operator cab (moves up to 36 in) + hydraulic gull-wing engine access door
Fluid Capacities	Fuel: 125 gal (473 L)

Unrivaled Drawbar Pull on Steep Slopes: The 1.3:1 drawbar-pull-to-weight ratio allows the operator to swing heavy trees and ascend steep, rugged forest terrain without losing momentum or stability.
Patent-Pending Service Access: The forward-sliding cab moves ahead up to 36 inches, paired with a full-length hydraulic gull-wing door that transforms into a slip-resistant maintenance platform for ground-level servicing.
On-Board Air Compressor: Includes an integrated on-board air compressor as standard equipment—an exclusive feature in the harvester market for immediate pneumatic work-tool connectivity.
Intelligent IQAN Hydraulics: Dedicated secondary pump drives head functionality smoothly while the IQAN system offers customized operator settings and real-time machine diagnostics.
All-Weather Operator Comfort: Features an enclosed, climate-controlled cab equipped with a 1.25-inch polycarbonate safety window, air-knife clearing system, heated air-ride suspension seat, and exterior LED working lights.

Industrial forestry harvesting, timber felling, and processing in dense pine and hardwood stands.
Compatible with both fixed harvesting heads (e.g., Barko CF18 / CF22) and dangling harvesting head configurations.
