The OFF GRID LX 45/90 Battery Storage 45kVA system provides high-capacity, portable lithium-ion power—ideal for silent, emission-free energy backup or hybrid operation with generators.
Description
Documents
Silent, emissions-free high-capacity portable power with hybrid generator support.
Key Features
Delivers 45kVA (36kW) continuous, with up to 112.5kVA (90kW) peak surge for 5 seconds
Zero noise and emissions in standalone mode—perfect for worksites, events or backup power
Hybrid-ready: can serve as a silent partner for generators, automatically handling light loads to save on fuel and maintenance
Recharges from grid, generator, or solar—site flexible and reliable
Rugged, weatherproof enclosure for demanding environments (IP34 protection)
Built-in safety features: overload, overheating, and low battery protection
Portable and easy to install—just connect equipment and it’s ready to operate
Technical Specifications
Phase
Single-phase / Three-phase 230/400V 50Hz
Continuous Power
45kVA / 36kW
Peak Power (5 sec)
112.5kVA / 90kW
Voltage
230/400V
Frequency
50 Hz
Battery Type
Lithium Ion
Nominal Capacity
90 kWh (approx. 72 kWh usable)
Cycle Life
4,000+ cycles
Maximum Input
125A 400/230V
Runtime
~2 hours at full power (varies by load)
Dimensions
201 cm (L) x 118 cm (W) x 201 cm (H)
Weight
Approx. 1,630 kg
Protection
IP34 (weatherproof)
Input Sockets
2 x 125A 400/230V IEC 60309
Output Sockets
Configurable (1 x 32A 230V, 2 x 32A 400/230V, 1 x 63A 400/230V, 1 x 125A 400/230V)
Inverter
Built-in, with protection against overload, short circuit, and overheating
Applications
Works as a silent energy source for construction sites or outdoor events
Rapid backup during blackouts
Supports and extends generator operation in hybrid setups
Ideal for locations where zero emissions and quiet operation are required
