The TruView™ Prime X-Ray System, manufactured by Creative Electron, USA, offers outstanding image quality in a benchtop configuration. The TruView™ Prime is ideal for use in Printed Circuit Board (PCB) inspection, (BGA and QFN) or semi-conductor failure analysis.
The TruView™ Prime S is the ideal parts counter system.
TECHNICAL SPECIFICATIONS:
- X-ray Source: 80 kV, 90 kV or 130 kV.
- Spot Size: Microfocus.
- System Resolution: Final image resolution depends on sample.
- X-ray Sensor: 3″ x 4″ or 5″ x 6″ (Models A,R) 14-bit flat panel. 12″ x 10″ or 17″ x 17″ (Model S) 16-bit flat panel.
- Sample Manipulation: Motorized or automated X,Y,Z motion. Stage tilt and sample rotation are available as options (Models A,R).
- System Dimensions: 31″ x 31″ x 35″ (Models A,S). 71″ x 31″ x 35″ (Model R).
- Maximum Visible Area: 12″ x 12″ (Models A,R). 17″ x 17″ (Model S).
- Included Software: TruView 6 Software. Please check TruView App Store for available applications.
- Included Computer: PC with Windows OS, fully networkable.
- Safety: FDA compliant and CE certified Cabinet fully shielded with multiple interlocks, keyed start and emergency stop switch. Certified to operate worldwide.
CONFIGURATIONS:
- TruView™ Prime Model A: Load and unload samples using the front door system. Motorized or automated motion system.
- TruView™ Prime Model R: Automated inspection of components in tape and reel. A must have for component inspection and counterfeit detection.
- TruView™ Prime Model S: Source on the top of the system and a large flat panel detector on the bottom, allowing samples to lie right on top of the sensor. System is ideal for NDT applications and parts counting.
