Centrifugal Pump | PAS 150HF 300 Get latest price

The PAS 150HF 300 centrifugal pump has a maximum capacity of 520m³/h, a suction/ discharge of DN150(6″), a maximum head of 51m, a maximum solids of 76 and a water cooled Deutz engine.

The PAS pump system consists of a centrifugal pump and a SuperDuo separator, which enables air to be separated from the liquid and be sucked by a vacuum pump – making automatic priming possible. Even with suction heights of several meters, the machine rapidly evacuates the air from the suction pipe and starts to pump. Additionally, thanks to the semi-open impeller, the PAS range is also suitable for pumping liquids with solids in suspension.

Both Atlas Copco and Varisco have decades of experience in designing and producing pumps. We have put those years of expertise into providing a solutions portfolio that works across multiple applications. The PAS MF (medium flow) range is packed with features that not only meet, but exceed the needs of the market. We are focused on an efficient, extremely versatile pump that is suitable for many industries, including construction, general dewatering and emergency applications, such as flood clean up.

Key Features

• Pump High efficiency: 70% (B.E.P.)
• Rapid "dry" priming Up to a height of 8.5 m (27.5 ft)
• High resistance To abrasive liquids and turbid sandy waters
• Semi-open impeller Solids handling up to 76 mm (3")
• Easy maintenance without lifting devices: hinged cover for direct access to the impeller
• Diaphragm vacuum pump oil free suitable for dry running: no contamination of the environment
• Wear plates cast iron or stainless steel (F11) wear plate, that is easily replaceable

Specifications

• Maximum Capacity: 520m3/h
• Suction/ Discharge: DN150 (6")
• Maximum Head: 51m
• Maximum Solids: 76
• Engine: Water Cooled Deutz
• Power: 51.2kW
