Compact Telehandler 29.6 kW | TH412Get latest price

Features:

• Equipped with the innovative VLS driver assist system (Vertical Lift System).
• Extremely small inside radius of 821 mm.
• Enormous lifting height of 4.5 m in combination with a payload of 1.2 t.
• Efficient 31 PS Yanmar engine—optional 40 PS available.
• Hydraulic quick change system for a great assortment ofattachments.

Operating data

• Lift height 4.259 mm
• Weight 2,700 kg
• Turning radius Tires 2,607 mm
• Total rotation angle of the tool carrier 148 °

Engine / Motor

• Engine / Motor manufacturer Yanmar
• Engine / Motor type 3TNV84T
• Engine performance 29.6 kW
• Displacement 1,496 cm3
• Emission standards stage IIIA
• Exhaust aftertreatment system -

Power transmission

• Traction drive Hydrostatic
• Speed Stage 1: 0-7 km/h
• Speed Stage 2: 0-20 km/h
• Service brake central Parking brake on all four wheels effective
• Standard tires 10.0/75 - 15.3 AS ET-40

Steering and operating hydraulics

• Steering angle max. 2 x 38 °
• Flow rate (with 22.6 kW) 42 l/min
• Flow rate (with 29.6 kW) 40 l/min

Kinematics

• Payload max. 1,200 kg
• Lift height Pin height 4,503 mm
• Payload at max. lift height 1,200 kg
• Payload at max. span 440 kg
