Cone Crusher | C2Get latest price

The McCloskey™ C2 Cone Crusher is the ideal portable secondary crushing solution for the operator requiring performance rates up to 300TPH. It is designed for optimum versatility in crushing spreads, with easy conversion from the finest to the coarsest cavity, adjustable speed to produce a higher percentage of on-spec product, and fewer crushing stages, lowering cost and saving energy.

Both the C2 & C2R have full-level features such as load and material level monitoring, full hydraulic push button Closed Side Setting (CSS) adjust and a full hydraulic relief system.

High Performance Cone Crusher

• MC200 Cone
• Tracked
• Integrated hopper with folding rear door
• I-beam plate fabricated chassis construction
• Large gap between crusher discharge and main conveyor
• Fast setup time
• Open chassis design for ease of maintenance
• High speed, high throw 200Hp cone

SPECIFICATION

• Engine: 360 Hp (268 kW)
• Cone: MC200
• Feed Opening: 38” (914mm)
• Feeder Belt Width: 42” (1050mm)
• Hopper Volume: 5m3 (6.5yd3)
• Crusher Drive: Direct Drive
• CSS Adjustment: Hydraulic
• Transport Height: 11’ - 1.8” (3.4m)
• Transport Length: 54’ - 4.7” (16.6m)
• Transport Width: 9’ - 1.4” (2.8m)
• Weight: 103,617 lb (47,000kg) (est.)
• Stockpile Height Main Conveyor: 14’ - 0.5” (4281mm)
• Main Conveyor Belt Width: 48” (1200mm)
