Compatible with mineral-based industrial fluids, portable systems such as the filter cart provide a cost effective solution to maintaining fluid cleanliness in multiple applications with the same lubricant.
Heavy duty, lots of options, exceptional value … Des-Case filter carts are uniquely yours, because you pick the options you need for your specific environment and application.
Standard
- Automatic pressure relief valve
- Non-bypass filter heads which prevent particles from passing by when the filters reach maximum saturation
- Dual-stage filtration
- 12' hose assemblies with various quick connect options
- Pneumatic wheels for easy mobility
- Industrial powder-coated paint
- Heavy-duty cart with oil catch pan
- One-year warranty
- 25 ft cord (for electric motors only)
Applications
- Decontaminating systems
- Flushing new or repaired systems
- Dispensing new oil
- Pre-filtering new oil
- Evacuating used oil
- Reservoir top-offs
- Flushing systems
- Collecting oil samples for analysis
Intended Use
- To be used for offline, secondary filtration and not inline filtration
- In general industrial environments, both indoors and outdoors (IP rating of 54)
- For filtering mineral-based industrial oils and most synthetic oils with a maximum operating viscosity range of ISO 680 at 100°F/38°C (3,000 ssu/648cSt) within ambient temperature ranges of -15°F to 150°F (-26°C to 66°C)
- Placed at the same level or below the equipment being filtered and within reach of the recommended standard 12 foot hoses
- This system should be stored and used on a level surface, right side up, in a low-traffic area, and connected to the appropriate power source
Operating Temperatures
- -40°F to 150°F (-40°C to 66°C) for standard unit with clear PVC hoses
- -20°F to 212°F (-28°C to 100°C) for custom unit with hydraulic hoses and Viton or EPDM seals
Materials
- Frame: Carbon Steel
- Paint: Industrial Powder Coat
- Filter Heads: Aluminum
- Fittings: Zinc Plated Steel and/or Brass
- Pumps: Aluminum/Steel
- Hoses: Clear PVC with steel wire or hydraulic hose
- Gaskets: Buna-N
Filter Indicators
- Filter indicator pops at 22 psid (1.55 bar) as warning that filter elements need to be replaced
Pump Relief
- Opens at 65 psi (5.49 bar)
Weight
- Approximately 100-150 lbs (45-68 kg). Will vary depending on options selected.
- Dimensions:
- 18.8" L x 21.5" W x 45.7" H
Viscosity Range
- Up to ISO VG 680 at 100°F / 38°C (3000 ssu / 648 cSt)
