Hygienic Mass Flow Meter | L-Cor 6000

Hygienic Flow Meter: L-Cor

Hygienic Flow Meter

Features:

Single straight tube design provides highest hygienic conditions
Titanium alloy for chemical resistance
+- 0.15 % mass flow accuracy
+- 0.002 g/mL density accuracy

Our Type S L-Cor 6000 Coriolis hygienic mass flow meters, built with titanium single straight tubes, are designed for hygienic applications. They’re your solution for highly accurate measurements of gases and shear-sensitive or viscous liquids, slurries, aggressive media, or media with a low flow velocity.

If fast and positive process fluid replacement or draining of the pipeline is what you need, then this is the mass flow meter for you.

Technical specifications

	L-Cor 6000
Measuring range	36 kg/h to 61 200 kg/h
Flow accuracy	± 0.15 % ± ZS*
Flow repeatability	± 0.075 % ± ½ ZS*
Density range	500 kg/m3 to 1,000 kg/m3 or 700 kg/m3 to 1,300 kg/m3 or 1000 kg/m3 to 1,500 kg/m3
Density accuracy	± 2 kg/m3
Nominal diameter	1/2” to 3”
Ambient temperature	- 40 °C to +55 °C
Process temperature	- 40 °C to +130 °C
Process pressure absolute	According to flange specification
Process connection	ASME B16.5 Class 150 Tri-clamp ISO 2852
Wetted parts	Titanium alloy
Approvals for potentially explosive atmospheres	ATEX, IECEx, CSA (C-US), NEPSI (CCC)
Outputs	2x analog, 2x pulse (frequency), 1x status output
Inputs	1x status input
Digital communication	Bell 202, Modbus RTU (RS-485), Profibus PA, Fieldbus
Transmitter version	Integrated, separately mounted, mounted in control cabinet
Certifications	EHEDG
