Industrial Acoustic Imaging Camera | Si124

Name: Industrial Acoustic Imaging Camera | Si124
Brand: Thermal Imaging Australia

The FLIR Si124 acoustic imaging camera can help you locate pressurized leaks in compressed air systems or detect partial discharge from high-voltage electrical systems.

In Stock

Specifications of this product

Acoustic measurement 124 low-noise MEMS microphones, real-time sound visualization
Sensitivity, accuracy <0 dB
Dynamic range >120 dB
Bandwidth 2 kHz to 31 kHz, adjustable range
Distance From 0.3 m (1.0 ft) up to 100 m (328 ft)
Display Size: 5 in, 800 × 480 Color: 24 bit RGB
Brightness: 1000 cd/m2 (adjustable)
Input device Resistive touchscreen
Power On indicator Red LED
Video image resolution 1640 × 1234
Video frame rate 25 fps
Acoustic image frame rate 30 fps
Zoom 2x digital zoom
Camera size 273 × 170 × 125 mm (10.7 × 6.7 × 4.9 in)
Camera weight Camera: 980 g (2.2 lb)
Battery size 90 × 145 × 65 mm (3.5 × 5.7 × 2.6 in)
Battery weight 985 g (2.2 lb)
Total weight, incl. all accessories 2.9 kg (6.4 lb)
Battery cord length 0.9 m (3.0 ft), extended 2 m (6.6 ft)
