Industrial Aerator | TEX-FLEXGet latest price

Features of this product

• The combination of a rugged stainless steel body enveloped by a highly resistant textile membrane makes the system perfectly suited for use in deep pools, as well as wastewater contaminated with oil, grease, acids and solvents.
• Conventional rubber membranes are typically subject to natural aging and wear. The textile membrane, which is highly resistant to chemicals and heat, provides a reliable alternative.
• The system delivers efficient oxygen supply and excellent mixing in the biological stage with minimal pressure drop.
• It is low maintenance, quick and easy to install, and can also be produced as a lift-out version. This means that it can be lifted in and out even when the basin is full.

Specifications of this product

• Amout of Air
• 1 – 25 Nm³/h
• Membrane Material
• Polyester Fabric
• Material Support Tube 1.4301
• Material Air Distributor 1.4301
• Diameter Pipe 60,3 mm
• Dimensions Air Diffuser 100 x 100 mm
• Aktive Membrane Length 990 mm
• Bubble Diameter 3 – 5 mm
• Pressure Drop 5 – 20 mbar
