Label Applicator Printer 80-120 litres/min | S5000 Get latest price

As with all Tronics equipment, the S5000 LPA is proudly designed and constructed in Australia, and is now in modular format, offering greater flexibility with a large range of thermal print engines. In addition to our “off-the-shelf” modular system, Tronics can offer engineered solutions to suit the specific needs and requirements of your application and operating environment.

S5000 Features

Custom Built

The Tronics S5000 Label applicator machine can print variable data labels on a variety of product stock and as such are custom built to our customer's requirements and specifications.

Print Methods

Print Methods: Thermal Transfer or Direct Thermal.

Labelling Speed

Labelling Speed: Contingent upon printer and label size or content.

Label Placement

Label Placement: Accurate to +/- 1mm when labels are made to specification and product handling is controlled and consistent.

Specifications

Media Types

Die cut self adhesive labels

Label Stock

Outside wound as standard

Max Standard Roll

305m (Optional 450mm)

Inner Core Diameter

76mm

Mains Supply

220/110VAC 50/60Hz 1 Phase

Power Consumption

440VA

Compressed Air

Clean, dry air at pressure of 6 bars (80-120 litres/min)

Weight

35kg (excluding the frame)
