Multi-process Welder | Vantage 400Get latest price

Use this multi-process welder for arc gouging with up to 8mm carbons, stick weld with up to 6mm electrodes and CV wire weld with up to 2.4mm wire.



Superior arc performance delivered by Lincoln Chopper Technology® ensures optimum productivity. You’ll also appreciate the VRD (Volt- age Reduction Device), which reduces OCV (open circuit voltage) in the CC-Stick weld mode for added safety.



This model efficiently generates 13,200 watts of AC generator power for your lights, grind- ers and power tools. Housed in a rugged, low-maintenance stainless steel enclosure, it’s loaded with many innovative service features. It’s a power package that’s excellent value!



 Innovative Service Access

- Lockable, removable sliding engine access door



provides ample space for engine and oil filter work without requiring a large clearance space on your truck.



-  Battery drawer on front of machine and top-mounted radiator cover provide convenient access to these systems.



-  Patent-pending tilt down control panel for easy servicing of internal components.



-  Patent-pending radiator cap cover is latched for easy access and is lockable.



(1) 2.4mm E70T-6 up to 260 IPM, 27V



Processes: Stick



                   DC TIG



                   MIG Flux-cored



                   Gouging











Simple to Operate-



- Select one of four Process Modes, including CC-Stick (up to 6mm), Downhill Pipe (for stick), Touch- Start® DC TIG or CV Wire (up to 2.4mm(1)), and then dial in the desired output.





Power-



- 13.2kw of AC power.

- Will power industrial equipment



such as a plasma cutter, pump or



inverter welder.

- 240 Volt and 415 Volt IP66 rated



outlets.





One of the most compact 400 amp machines available. Suitable for many pickup and service trucks.





Standard stainless steel roof, side panels and engine-access door deliver added protection and durability.



VRD Voltage Reduction Device- Reduced OCV in the CC-Stick weld mode for added safety.





Arc gouging with up to 8mm carbons.



- 4 cylinder, 1500 RPM Perkins diesel engine runs smoothly and quietly Standard engine gauges allow you to monitor performance at a glance.





- 96 dBA Lwa sound power (71 dBA at 7m) is one of the quietest 400 amp engine-driven welders available.
