PB-2580J-SA Series Industrial-grade Power Backup ModuleGet latest price

PB-2580J-SA is composed of eight 100F/ 2.7V supercapacitors offering 9250, 4600, and 2580 watt-second energy, allowing extra extended operation time to backup your system. Due to the patented CAP energy management technology, PB-2580J-SA can reliably supply up to 70W of power to the back-end system and automatically manage boot and shutdown without installing additional drivers/ software. In addition to the UPS-like power backup mode, it also offers two advanced ignition control modes for in-vehicle usage.

PB-2580J-SA can work with either standard box-PC or in-vehicle controller to provide a stable power supply and execute user-configurable power-on/ power-off delay according to IGN signal input. Featuring various modes, automatic shutdown control and up to 70W output power, PB-2580J-SA series can work with most off-the-shelf box-PCs. And with properties such as maintenance-free energy storage and uninterruptible power supply, the PB-2580J-SA series can prevent the connected back-end system from data loss during a power outage in harsh industrial environments

Key Features:

• Universal Standalone Power Backup Module Compatible with all Box-PCs
• Supercapacitor-Based, -25 to 65°C Wide Temperature Operation
• Up to 2580 Watt-Second Energy Capacity
• Maximum 70W Output Power for the Connected Back-End System
• Over 10 years Lifespan, and 500,000 Charging/ Discharging Cycles
• Patented CAP Energy Management Technology*
• Extending Back-up Time in the Event of an Unforeseen Power Outage
• Monitoring Energy and Power Consumption to Extend Operation Time for Safe System Shutdown
• Versatile Operating Mode
• *R.O.C Patent No. I598820
