The material used for the construction of these pulleys is GG-25 Cast Iron. Each pulley undergoes stringent balancing tests to ensure each pulley functions efficiently.
The pulleys are finished in a black coating this acts a s a primer to help protect the pulleys from environmental factors
Our Taper Bored stock pulley range covers: SPZ, SPA, SPB & SPC
Circumferential speeds of up to 40 m/sec are permissible.
Also available in aluminium.
Vee Pulley Stock Range Includes.
SPA 80mm - 500mm , 1 - 5 grooves
SPB 125mm - 1250mm , 2 - 8 grooves
SPC 200mm - 1250mm , 3 - 8 grooves
SPZ 56mm - 355mm , 1 - 4 grooves
Vee Belt Stock Range Includes.
A, B, C, D & M Section
SPA, SPB, SPC & SPZ Section
Poly-V Pulley and Belt drives are ideal where you have space restrictions, high ratio or high torque drives. With only one belt, tensioning is easy and you do not have to worry about matching belts.
The Poly V Pulley will also run quieter than timing pulley and chain drives and do not slip like standard V-Pulleys.
Pulley
'J' Section 'L' Section 'M' Section
20mm to 400mm dia 75mm to 4oomm dia Manufactured against order
4 Groove to 16 Groove 6 Groove to 20 Groove
A full range of belts in 'J', 'L' & 'M' section is also available
Belts
'J' Section 'L' Section 'M' Section
150J (381mm long) to 500L (1270mm long) to 900M (2286mm long) to
980J (2498mm long) 2400L (6096mm long) 6010M (15266mm long)
