Product Features:
- Provides spindle rotations of up to 25.0 (16.6)* rpm, for high speed indexing
- Includes rigid body design to reduce deformation under heavy load
- 320mm diameter faceplate with max speed of 25 (16.6*) rpm and clamp torque of 2800 Nm
Product Specifications:
- Table diameter (mm): Ø320
- Register diameter on faceplate (mm): Ø130
- Spindle Through Hole Diameter (mm): Ø105
- Centre Height (mm): 225
- Clamping method: Pneumatic
- Clamping Torque (N.m in pneumatic 0.5MPa): 2800
- Gear ratio: 1/120
- Max Spindle Speed: 25.0 (16.6)*rpm
- Indexing Accuracy (sec): 20
- Repeatability (sec): 4
- Weight: 145 kg
To contact Dimac Tooling about Rotary Tables | GT 320 use Get a quote.
