Screen Separator | Cup and Drum Screen | DRUMGUARD

Name: Screen Separator | Cup and Drum Screen | DRUMGUARD
Brand: Spirac

Supplier: Spirac

The DRUMGUARD screen is a simple and robust solution to applications where there is a requirement to screen large volumes of water. Typical applications include power generation intakes and desalination plants.

In Stock

For many years, this type of screen has been used on sewage works for fine inlet screening and sea outfall use. The screening panels are generally perforated stainless or plastic for sewage applications, and woven wire mesh for water intakes.

Technical Information:

Common installations at Wastewater Treatment Plants, Seawater & Pumping / Intake Stations.
Cup Screens from 1 m (3 ft) diameter. Drum Screens up to 18 m (60 ft) diameter.
Able to screen large volumes of water
Perforated panels in stainless steel or Ultra-high-molecular-weight polyethylene (UHMWPE) depending on application
Screening size = 2mm to 6mm.
Material of construction, carbon steel painted as standard or stainless steel.
Options: Single, dual or variable speed drive (3 & 6m/min peripheral speed) ATEX certified if required for use in hazardous areas. Rotary cleaning brush option for enhanced panel cleaning on sewage applications.
A fish-friendly version is also available.
