Features of this product
- The system has independent charging radio shuttles, allowing pallets to run on a guide rail with the control of a manual radio
- The shuttle can reach under the pallets to access the goods that are stored deep within the rack system, lifting them from the guide rail and sending to the front-end exit. Then you can use either a forklift to extract the goods or move the shuttle to another guide rail
- The Shuttle Rack System is a high density storage system that allows for excellent utilisation of space
- The system has many advantages, it allows storage of different reference numbers of codes per module
- It saves time unloading pallets. Safer to use and less damage to the racking system as there is less interaction with a forklift
- It is also suitable for cold storage systems.
Specifications of this product
- Standard Pallet: W1165 ×D1165
- Available Size: W1250 D1100
- Deflection of Pallet: Max 20mm
- Weight of loading: Max 1500kgs
- Model of Runnning: On the rails
- Running without loading: 0.9m/s
- Running with Max loading: 0.8m/s
- Time of lifting: 3s
- Distance of Lifting: 45mm
- Distance between pallet and rail: 20mm
- Outside Dimensions: 1150 ×1150 ×150
- Weight of shuttle: 260kgs
- Times of Charging: 6 Hours
- Temperature of warehouse: Normal:0-45° Cryogenic -1- -35°
To contact Just Warehousing about Shuttle Racking use Get a quote.
