Heavy-duty construction with premium grade steel for superior durability and load handling. Specifications & Features- Chassis Construction: Fabricated 'I' Beam, with 100 x 16 mm top flange, 100 x 20 mm bottom flange, and 5 mm Grade 350 steel webbing
- Tub Construction: 100 x 100 x 6 mm RHS subframe; 100 x 75 x 6 mm RHS draw arms
- Standard Floor: 5 mm Grade 350 steel
- Standard Wall: 3 mm Grade 350 steel
- Skid Plate: 10 mm thick with bolt-in king pin for chassis; 16 mm thick for TOA
- Braking System: Air Brake Corporation EBS Air Brake with Yard Release (Options: ABS and EBS)
- Landing Legs: JOST T520 Two Speed Legs with pad feet
- Axles: Standard York 127 mm Road Baron axles, 10-Stud 285 PCD hubs, enclosed 'S' cams, grease filled (Options: Spider, Disc Brake, BPW, TMC)
- Suspension: York tapered bush cast with 8 leaf springs (Optional: 3 leaf springs, TecAir, Duratrac airbag)
- Hoist: JOST hoists, 50 tonne standard in all grain tippers
- Toolbox: One steel lockable toolbox
- Tyre Carrier: Dual bolt-on to underside of trailer
- Lighting: One piece wiring loom, HELLA LED jumbo rear and side lights, 6 mm wiring for road train
- Options: Pelmet roll tarp, grain door, two-way tailgate, sub-door in front wall, air tailgate switches, weight gauges, airbag suspensions
Dimensions| Length (Chassis) | 7.9 m – 10.1 m |
| Length (TOA) | 9.1 m – 11 m |
| A Trailers Length | 8.2 m – 9.7 m |
| Max Width | 2.5 m |
| Height | 900 mm – 2000 mm |
Combinations & Build Types- B Double
- B Triple
- Road Train
- PBS Combinations
To contact Freight Master Trailers about ST2/ST3 Steel Grain End Tipper Trailer use Get a quote.
