Static Torque Sensor | CZL595

Name: Static Torque Sensor | CZL595
Brand: ZHYQ IOT PTY LTD

CZL595 Torque sensor is the precision measuring instruments to measure torque, revolving speed and the power of the mechanical.

Call for more details

Applications for this product

Static torque measurement, railway locomotive power, car power, tractor power, aircraft power, ship power, mining machinery power, sewage treatment system

Features of this product

Resistance strain for sensitive components and integrated circuit consisting of integrated products, high precision, stable and reliable performance.
Torque measurement in a wide range, easy to install and use.
Static torque measurement. End for key (or within four key) connection, side for flange connection.

Specifications of this product

Model	CZL595
Rated Load (Nm)	0-50, 100, 200, 500, 1000
Rated Output (mv/v)	1.5±10%
Zero Output (%F.S)	±2.0
Nonlinearity (%F.S)	±0.1, 0.3
Hysteresis (%F.S)	≤±0.05
Repeatability (%F.S)	≤±0.05
Creep (%F.S/30mins)	≤±0.03
Rated Output Drift by Temp. (%F.S/10?)	±0.03
Zero Drift by Temp. (%F.S/10?)	±0.03
Input Resistance (Ω)	750±10
Output resistance (Ω)	700±5
Insulation (MΩ/100VDC)	≥5000
Work Voltage (VDC)	10~15
Compensated temperature range (? )	-10~+60
Use temp. range (? )	-20~+65
Safe overload (%F.S)	150
Ultimate overload (%F.S)	200
Cable Size	?5.2 x 3m
Electric Connection	RED/E+,BLK/E-,GRN/S+,WHT/S-
Material	Stainless steel or alloy steel
