TIG Welder | Typhoon 330

Name: TIG Welder | Typhoon 330
Brand: Everlast Welders

Supplier: Everlast Welders

The large 5.1" HD Color LCD screen features the ability to see and set all the parameters at-a-glance on a single screen without endless hidden menus or complicated series of button presses to access and adjust the parameters.

Receive 1-3 days from order

Looking beyond the apparent simplicity of intentional design, you will find a long list of well thought out features that include items like adjustable wave forms on DC pulse, five AC wave forms (yes, five), independent amplitude and split AC wave form control.

The list of features continue to peal back like an onion though, in AC mode, with not only the ability to set AC amplitude (positive amperage vs negative amperage) independently, you can also set the machine to split each half of the ac cycle into one of the 5 separate wave forms, and set the AC frequency up to 400Hz.

The real difference comes through in AC advanced pulse though with a mixture of both AC and DC negative that allows you to achieve the penetration of a machine with 500A or more. Of course with a standard DC pulse frequency up to 999.9 Hz and the standard AC pulse frequency up to 400 Hz, you'll have maximum control on thin materials as well.

Features of this product

Advanced Digital IGBT Inverter Technology.
HD (720) 5.1" LCD color screen with easy to read contrast.
Intuitive navigation and layout of settings.
Power Factor Correction.
Dual 120/240V operation.
F.A.C.C.T. (Fan and Cooler Control Technology)
5 AC Wave forms: Adv. Square, Soft Square, Trapezoid, Triangle, and Sine.
Split AC Wave form control technology. Select wave form shape of individual half-waves in AC.
Independent Amplitude Control over EN and EP Amps in AC.
DC Wave form shaping for more control.
DC Pulse up to 999.9 Hz. AC Pulse up to 400 Hz.
AC Adv. Pulse (Mixed AC/DC pulse up to 10 Hz) increases Aluminum penetration similar to 350A or greater of standard machines.
AC frequency up to 400Hz.
True low amp starts measured at 2A DC and 3A AC.
Single page layout without hidden menus to access.
Almost all settings visible at a glance.
Capacitive HV/HF arc starting: No Points to adjust.
Selectable to start Electrode Positive or Electrode Negative.
Selectable for Tungsten size for quicker starts.
Advanced PowerSet menu makes setup easy and quick.
70% Duty Cycle TIG and Stick at max output.
230A TIG/ 200A Stick maximum output.
30 program memory with lock function to prevent tampering.
