Vertical Vacuum Precision Investment Casting Furnace | PC-200Get latest price

Parts with an Equiax grain structure are easily produced in a VPIC and with the addition of a Mold Heater and Water Cooled Chill Plate, Directionally solidified and Single-Crystal castings are able to produced as well.  Consarc offers many features to ensure the highest productivity including, automatic baffle exchange, liner and billet charging, and an independent liner dump chute.  Whatever your process entails a Consarc VPIC can be tailor designed to suit your needs.

Features of this product

• Vertical, or pitless vertical furnace configurations.
• Door mounted, rapid exchange melt coils, without any power or water connections internal to the vacuum chamber.
• Melt coil translation system for accurate pouring with Teach Pour
• Vertical billet charging with single use liner insertion and removal capability
• High speed mold transfer with multi position control
• Precision mold withdrawal system
• Large capacity vacuum systems for fast mold chamber evacuation
• Automatic temperature control of molten metal with optical pyrometer
• PLC based automated controls with full SCADA
• Stainless steel melt chambers for continuous high vacuum operation
• Robust delta seals on main chamber sealing flanges
• Water cooled articulating mold chamber isolation valve (Vertical Units Only)
• Custom engineered and designed equipment specifically for individual user’s process

Specifications of this product

• Max Cast Weight: 200 kg
• Max Mold Diameter: 1000 mm
• Max Mold Diameter (DS): 800 mm
• Mold Height: 1500 mm
• Mold Height (DS): 1000 mm
• Isolation Valve Diameter: 1050 mm
• Melting Power Supply: 325 kW
• Optional Mold Heating Power Supply: 225 kW
