Description

• Dynamic accumulation
• Improves line throughput
• Tremendous accumulation space!
• Compact design
• Zero pressure
• First-in / First-out

The AccuVeyor® is designed for dynamic accumulation of products between the up and down stream machines. By uncoupling the processes of these machines micro stops will be prevented and this will result in a constant fl ow of products. This will increase the overall line performance, effi ciency increases of 27% have been achieved! The AccuVeyor® is your true alternative for single-lane accumulation.

AccuVeyor® AVx
The AccuVeyor® AVx is one of the accumulators in the AccuVeyor® family. The AccuVeyor® AVx is designed for medium sized primary or secondary packed goods transported in a single row. The belt width can vary from 100 to 600 mm.

Accumulation principle
The AccuVeyor® AVx patented accumulation solution is based on continuous loading and unloading different parallel spiral conveyors. The system consists of diverter, a spiral conveyor with multiple tracks and a combiner. When a line is full the diverter will select the next empty track to fill. On the discharge the combiner empties the line filled last in a FiFo sequence. To increase accumulation capacity, the in-feed divert sequentially selects a different lane to fill. The accumulation / storage length can vary from 50 to 500 meters!

Configurations
• Built to suit your accumulation needs, product and space.
• The AccuVeyor® comes in full wash down stainless or economical painted material configuration.
• There are single and a double/multi spiral configuration available
