Cupellation Furnace | Electrical (50 place; 100 place & 168 Place)Get latest price

Specifications:

• Construction
  • Cabinet of 2mm zinc anneal steel lined with insulating firebrick.
  • Backed with Superwool insulation board.
• Muffle Dimensions

  • 50 Place (Muffle #4) —200mm high x 260mm wide x 460mm deep
  • 100 Place (Muffle #5) —300mm high x 480 mm wide x 560mm deep
  • 168 Place (Muffle #8) —370mm high x 680 mm wide x 670mm deep
• Heating Elements
  • 12 x Silicon Carbide elements rated at 10.5kW/15kW/24kW, 3 Phase.
  • Power supply is per a multi-tapped double wound transformer
• Door Operation

  • 50 Place— Counter-balanced, rising
  • 100 Place: Pneumatic rising. Operated by foot control
• Temperature Control
  • Electronic, Automatic control 1200oC, Type “K” Thermocouple.
  • High temperature alarm, over temperature controller
• Electrical Requirements

  • 50 Place :   10.5kW, 3 Phase
  • 100 Place : 15kW, 3 Phase
  • 168 Place : 24kW, 3 Phase
  • Voltage is customized to destination country)
• Approximate overall dimensions with door open

  • 50 Place—1785mm high x 695mm wide x 830mm deep
  • 100 Place—1895mm high x 1120 mm wide x 975mm deep
  • 168 Place—1790mm high x 1310 mm wide x 1075mm deep
