DWS Laser System Measuring accuracy: 5mm | CNK-1100R (Belt Scale)

Name: DWS Laser System Measuring accuracy: 5mm | CNK-1100R (Belt Scale)
Brand: Techsorta Pty Ltd

This is a volume measurement equipment with a belt scale. It combines infrared detection depth, three-dimensional vision technology and proprietary algorithms, including volume measurement, visual code reading, weighing and other modules.

Receive 1-3 days from order

The measurement accuracy reaches ± 3 mm and the weighing accuracy reaches ± 5 g, which saves 60% time and reduces operating costs by 80%.

Product Parameters

Measuring technology: 3D binocular vision technology
Measuring range: 20*20*10~600*600*600mm
Installation height: 1.5 meters
Measuring accuracy: 5mm
Measuring time: <1S
Automatic scanning: intelligent/industrial camera code reading
Can read: one or two-dimensional code
Barcode accuracy: >10mil (0.25mm)
Upper computer: split or integrated (standard or optional)
Electronic scale: desktop scale or customized according to user needs
Electronic scale accuracy: t50g 1/3000
Printer: optional module (optional expansion docking)
Manual scanning: optional module (wired or wireless scanner)
Peripheral accessories: workbench (optional components)
Data interface: customized development of docking program according to needs
Application industry: logistics express, cross-border e-commerce, chain supermarkets
