EtherNet/IP to Siemens Industrial Ethernet Communication Gateway

Name: EtherNet/IP to Siemens Industrial Ethernet Communication Gateway
Brand: Prosoft Technology

Supplier: Prosoft Technology

19 Recent ViewsIn Stock

ProSoft Technology’s EtherNet/IP™ to Siemens® Industrial Ethernet communication gateway allows high-speed bi-directional data transfers between EtherNet/IP™-enabled controllers or devices and Siemens® S7 PACs, including S7-200s, S7-300s, S7-400s, S7-1200 and S7-1500 PACs.

In addition, the gateway includes several features, including data prioritization, that allow for simplified integration, reduced commissioning time and optimized performance.

Features and Benefits

Data prioritization: Multiple I/O connections allow you to set RPIs for status and/or control data, optimizing Ethernet bandwidth.
Includes an embedded EDS Add-On Profile, allowing for simplified integration and reduced commissioning time.
Includes a SD card slot (SD card optional) for storing configuration files. This can be used for disaster recovery.
ProSoft Discovery Service: This utility allows your PC to see the gateway and change its default IP address without being on the same subnet.
Secure module configuration via module switch (v1.04 and greater).
Up to 4000 16-bit registers can be used to exchange large amounts of data.

Specifications

EtherNet/IP™ Specifications

Specification	Description
Number of Class 3 Server Connections	5
Supported PLC Types	PLC2, PLC5, SLC, CLX, CMPLX, MICROLX
Supported Message Types	PCCC and CIP
Class 3 Client Connections	Connected - 2 Unconnected - 1
Number of Class 1 I/O Connections	2
I/O connection sizes	248/248
Max RPI time	5 ms per connection
CIP Services Supported	0x4C - CIP Data Table Read 0x4D - CIP Data Table Write
Command List	Support for 100 commands per Client, each configurable for command type, IP address, register to/from addressing and word/bit count.
Command Sets	PLC-2/PLC-3/PLC5 Basic Command Set PLC5 Binary Command Set PLC5 ASCII Command Set SLC500 Command Set

Siemens® Industrial Ethernet Specifications

Specification	Description
Supported PLC Data Exchange (Read and Write)	Siemens S7-200, Siemens S7-300, Siemens S7-400, Siemens S7-1200, Siemens S7-1500
Supported Register Types	DB, Inputs, Outputs, Flags, Counters, Timers
Supported Clients	20
