General Purpose Pressure Transducer

Name: General Purpose Pressure Transducer
Brand: Slentech

Supplier: Slentech

The general purpose pressure transducer is the “all-rounder” and suited to fit most varied applications.

35 Recent ViewsIn Stock

With its remarkably wide measuring range(-1 to 1000 bar) it is extremely resilient. Thanks to its modular system, it allows for most diverse customized plugging and threading configurations that can be supplied within very short time. Its robust design guarantees highest reliability even in very harsh environments.

Due to its modular design with a fully welded stainless steel membrane (all material in contact with the measured media is stainless steel) and its adoptable electronics, this is the optimal substructure for pressure transducers for industrial applications. All pneumatic and hydraulic systems can be equipped with this pressure transducer.
Pressure ranges from 0 to 1 bar relative or vacuum measurement of -1…0 bar or any ranges up to 1000 bar can be individually selected – or standard ranges can be used. Our production capability starts at 1 piece per order / lot. Standard ranges such as 10 or 250 bar are as easy as specified ranges of 0 to 11.5 bar or 4.5 to 324.2 bar.

Features:

Measuring ranges -1 to 1000 bar
All standard signals for industry, hydraulics and pneumatics
Temperature range of media -40°C to 125°C
Protection class IP67 (special version up to IP69K – depending on welding & housing)
Compact and rugged model in stainless steel
High flexibility for options thanks to modular design
Highly reliable

Approval:

German Lloyd (GL) for marine application
ECE Directive R110 engines powered with compressed natural gas
CE Declaration of conformity 2014/30/EG + 2014/68/EG
Railway application DIN EN 50155

Applications:

Industrial applications
Marine application
Railway application
Hydraulics / Pneumatics
Industrial Equipment and Automation technology

To contact Slentech about General Purpose Pressure Transducer use Get a quote.
