High Speed USB Output PX409 Series Pressure TransducerPrice Guide:$1,070Get latest price

The PX409 High-Speed USBH Series connects directly to your computer. Free software makes data logging and charting your readings a simple task. Also included are .NET drivers and a command set for command line access. The micro-machined silicon design is ideal for pressure or level applications in laboratory, test platforms, or bio/pharmaceutical applications as well as industrial applications that require a rugged, high accuracy transducer. This sensor provides a very stable transducer with an exceptional high accuracy of ±0.08% and a broad compensated range of -29 to 85°C (-20 to 185°F). The modular construction allows for fast delivery of most configurations and fittings.

• FAST DELIVERY!
• High Speed USB Pressure Sensor! 1000 Reading/Second
• Free Downloadable Software
• Micro-Machined Silicon Sensor
• 316L SS Wetted Parts
• High ±0.08% BSL Accuracy
• Excellent Long Term Stability
• USB 2.0 and Below Compatible
• Standard USB Connector Termination
• Shock and Vibration Rated
• Ruggedized with Secondary Containment
• New PX409 USBH Product Release With Upgraded High-Speed Software!

Specifications

• Accuracy: 0.08% BSL (linearity, hysteresis and repeatability combined)
• Resolution: Up to 5.5 significant figures
• Zero Balance: ±0.5% full scale typical ±1% maximum (±1% typical, ±2% maximum for 2.5 psi and below)
• Span Setting: ±0.5% full scale typical ±1% maximum (±1% typical, ±2% maximum for 2.5 psi and below). Calibrated in
• vertical direction with fitting down
• Temperature Compensation (Over Compensated Range):

  •     Span: Range > 5 psi: ±0.5%
  •     Range ≤5 psi: ±1.0%
  •     Zero: Range > 5 psi: ±0.5%
  •     Range ≤ 5 psi: ±1.0%
• Minimum Isolation:

  •     100 MΩ @ 50 Vdc case to sensor
  •     2 MΩ @ 50 Vdc case to output terminations
• Pressure Cycles: 1 million, minimum
• Long Term Stability (1-Year): ±0.1% full scale typical
• A to D Conversion: 24-bit
• Shock: 50 g, 11 mS half sine, vertical and horizontal axis
• Vibration: 5-2000-5 Hz, 30 minute cycle, Curve L, Mil-Spec 810 figure 514-2-2, vertical and horizontal axis
• Bandwidth: DC to 1000 updates per second typical (±3%)
• Power Consumption: 0.35 W typical
• CE Compliant: Meets industrial emissions and immunity EN61326
• Environmental Protection: IP65
• Secondary Containment
• Gage/Vacuum/Compound Pressure:

  •     10 inH₂O to 5 psi: to 1000 psi
  •     15 to 1000 psi: to 3000 psi
  •     1500 to 5000 psi: to 10,000 psi
• Absolute/Barometric Pressure:

  •     5 to 1000 psi: to 6000 psi
  •     1500 to 5000 psi: to 10,000 psi
• Overpressure
• Gage/Vacuum/Compound Pressure

  •     10 inH₂O: 10 times span
  •     1 psi: 6 times span
  •     2.5 psi to 1000 psi: 4 times span
  •     1500 psi yo 5000 psi: 7250 psi maximum
• Absolute/Barometric Pressure:

  •     5 psia: 6 times span
  •     15 psia to 1000 psia: 4 times span
  •     1500 psia to 5000 psia: 7250 psia maximum
• Wetted Parts: 316L stainless steel
• Weight: 200 g (7 oz)
• Operating Temperature Range: -40 to 85°C (-40 to 185°F)
• Compensated Temperature:

  •     Ranges >5 psi: -29 to 85°C (-20 to 185°F)
  •     Ranges ≤5 psi: -17 to 85°C (0 to 185°F)
