Specifications of this product
| LCD | |
|---|---|
| Screen Size / Ratio | 7 inches / 16:9 |
| Resolution | 1280 (H) × 720 (V) RGB |
| Active Area (mm) | 156.48 (H) × 80.136 (V) mm |
| View Angle (H/V) | 80 / 80 / 80 / 80 Degree |
| Brightness (nits) | 560 nits (typical) |
| Contrast Ratio | 1000:1 (typical) |
| Backlight Type | LED |
| TOUCH | |
| Type | Projected Capacitive with Multi-touch |
| I/O | |
| Multi-IO | 1 x DVI-D 29 pins Connector for DVI-D Single Link Video, Touch (USB 2.0), Line in, MIC out, and DC 9~48V Power input * SINTRONES custom pin definition for SINTRONES optional cable only |
| Secondary Video Input | 1 x HDMI |
| Function Key | 6 x Touch Hotkeys |
| AUDIO | |
| Microphone | 2 x Bulit-in Digital MIC |
| Speaker | Stereo Speaker with Built-in Amplifier |
| MECHANICAL | |
| Dimension | 188.5 (L) x 124.2 (W) x 31.4 (H) mm |
| Mounting | VESA MIS-D 75 mm |
| Weight | 510g |
| IP Rating | (Front) IP65; (others) IP4X |
| POWER REQUIREMENT | |
| Power Input | 9V - 48V DC Power Input |
| ENVIRONMENTAL | |
| Operating Temp. | -20°C ~ 60°C with 0.6 m/s airflow |
| Storage Temp. | -40°C ~ 80°C |
| Relative Humidity | 10% RH – 90% RH (non-condensing) |
| Vibration | IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis MIL-STD-810G, Method 514.6, Procedure I, Cat.4, Operating |
| Shock | Operating: MIL-STD-810G, Method 516.6, Procedure I, Trucks and semi-trailers=15G (11ms) |
| Certifications | CE, FCC Class A, E13 |
| ORDERING INFORMATION | |
| Model Number | VDM-700HD |
| Description | 16:9 7" 560nits In-Vehicle Monitor w/ P-CAP Multi-touch |
