The VisionSAM series support both Ethernet and Power-Over-Ethernet (PoE) that makes it ideal for a wide range of M2M applications including video surveillance, remote networking, industrial monitoring, fleet management, SCADA systems, etc.
Features of this product
- Enclosure is made of polycarbonate case: UV-stabilized recommended for outdoor use, designed to meet IP 66/67 & NEMA 4, 4X, 12 & 13 ratings.
- IP67 rated power, Ethernet, and antenna connectors.
- Switchable Power-Over-Ethernet (PoE) feature, compliant to 802.3af (48Vdc, 0.35Amp @ 17watt maximum)
- Static/Dynamic routing with TCP/IP
- Advanced routing RIP/VRRP and configurable static routes
- NAT and Port forwarding, MAC address binding
- Advanced security features: OpenVPN, PPTP client and IPSecVPN function
- NTP/DST synchronisation
- SNMP with cellular specific MIB, PPPoE and MAC address filtering
- Remote login via Static IP or DDNS for dynamic IP connection
- Periodic reset and SIM management
- Built-in SMS functionality, capable of sending and receiving SMS
- AT-Commands Over Ethernet capability
- MIMO feature (4G) and antenna diversity (3G)
- Satellite connectivity available upon request
- Optional GPS capability
Specifications of this product
- Dimensions: 200 x 120 x 90 mm
- Package Content: 1 x VisionSAM Modem/Router, 2 x Outdoor-rated, Multi-band antennas (Operating Frequency Band: 700 MHz -2.2 GHz), 1 x Ethernet cable
- Optional Accessories: N-male antenna connector dust cap, 100-240Vac PSU with IP67-rated power plug, IP67 Ethernet cable set
- Operating Temperature: -30°C, +85°C
- Storage Temperature: -40°C, +85°C
- Power: 9-12Vdc (can be supplied with a 100-240Vac PSU as accessory)
To contact Intercel about Industrial 4G Modem Router | VisionSAM use Get a quote.
