Load Cell Torque and Thrust Bi Axial MBA500Get latest price

The MBA500 Torque and Thrust Bi-Axial Load Cell measures reaction torque movements as well as compression and tension loads with a selection of models measuring load capacity between 222.411 to 2224.11N and Torque Capacity between 5.6492 to 56.4924 N-m. It has a compact design, is temperature compensated, made from Aluminium and 0.2% nonlinearity.

Used for product testing, robotic assembly, grinding and polishing.

The MBA500 is a Torque and Thrust Bi-Axial Load Cell. Firstly, it is temperature-compensated and constructed of all aluminium. Plus, this torque/thrust sensor is able to achieve an impressive 0.2% nonlinearity and yet provide 150% (22.67 to 68.04 Kgs) over-capacity.

Designed to measure reaction torque moments as well as tension and compression loads, its performance and high precision is achieved through two separate outputs for applied torque and thrust forces.

Used throughout industry

for product testing, robotic assembly, grinding and polishing. The MBA500 Torque and Thrust Biaxial Sensor offers a solution for measuring Loads in tension and compressions as well as torque in a clockwise and anti-clockwise direction. The MBA500 is compact weighing only 184 grams in a compact design.
