Mini Excavators | SY10UGet latest price

The SANY SY10U mini excavator is setting new benchmarks for compact performance in the one-tonne class. With zero tail swing, an offsettable boom, and a telescopic undercarriage, it delivers exceptional versatility and stability—even in the tightest worksites.

With a compact width of just 745mm and an operating weight of 1,195 kg, the SY10U combines lightweight agility with serious digging power, making it the ideal choice for landscaping, municipal works, and residential projects across Australia, New Zealand, and the Pacific Islands. Powered by a 8.8 kW Kubota engine, it offers fuel-efficient performance day after day. The advanced hydraulic control system ensures smooth, responsive, and precise operation, giving operators confidence with every move.

Designed with operator comfort in mind, the SY10U also features a high-back seat, adjustable armrest box, and an ergonomic operating platform.

Since its launch, the SY10U 1-tonne excavator has quickly gained popularity overseas and received outstanding reviews from customers worldwide.

Key Features

• Zero-tail swing capability
• Telescopic undercarriage (745-1100mm)
• High back suspension seat
• Ergonomic extension system increases legroom from 500mm to 650mm

General Information

• Weight

1195 kg

• Standard bucket capacity

0.025 m³

• Transport length

3018 mm

• Transport width

745/1100 mm

• Height over cabin/ROPS

2290 mm

• Engine

Kubota Diesel D722

• Rated Power

8.8 kW

• Engine Revolutions

2200 rpm

• Emission Stage

Stage V

• Max. digging depth

1868 mm

• Max. digging reach

3539 mm

• Max. Speed

2.1/3.4 km/hr

• Bucket digging force (ISO)

12.9 kN

• Arm digging force (ISO)

6.9 kN
