Exceptional lifting capacity and compact design ideal for urban construction. Key Features- Compact 17-ton excavator with the shortest tail swing in its class
- Large, comfortable ROPS cabin with low noise level (68 dB (A))
- 175 hp Cummins engine delivering over 400 l/min hydraulic flow for top performance
- High digging speed and breakout force for robust excavation
Excavator Design- Two-piece boom made from high tensile steel with closed profiles
- Dipper arm lengths: 2.0 m, 2.5 m, and 3.0 m available
- Options for hydraulic quick hitch and tilt rotator
Brakes & Axles- Dual circuit system with oil-immersed brakes on all wheels
- Automatic excavation brake is standard
- ZF axles with planetary hub reduction; oscillating front axle (+/- 8º)
Hydraulic System- Dual-circuit Load Sensing and high-pressure hydrostatic slew system with electronic power control
- Mode Control for precision and ECO-Mode for fuel efficiency
- Up to 3 adjustable hydraulic circuits for various implements
Hydraulic SpecificationsWorking hydraulics | 319 L/min |
Slew hydraulics | 88 L/min |
Hydraulic circuit 1 (ZV1) | 0-200 L/min |
Hydraulic circuit 2 (ZV2) | 0-100 L/min |
Hydraulic circuit 3 (ZV3) | 100-200 L/min |
Engine- Cummins B 4.5L Stage 5 engine with DOC, DPF & SCR catalyst and AdBlue additive
- 16-valve common-rail turbo-diesel with intercooler
- Maximum power: 175 hp (129 kW) at 2,200 rpm; maximum torque: 780 Nm at 1,500 rpm
- Fuel tank: 280 litres; AdBlue tank: 31.5 litres
Operation & Controls- Joysticks with up to 4 proportional servo functions, rollers, and 4 buttons
- Individual electronic control of pressure and oil volume for optional hydraulics
- Two-piece boom operated with foot pedal independently
- Multi-adjustable armrests
Chassis & Undercarriage Options- Six undercarriage variants including dozer blades and stabilisers (rear/front)
- Customize to suit specific job requirements
Technical DataMachine weight (A1 variant) | 18,700 kg |
Width over standard tyres | 2,530 mm |
Clearance height, cabin | 3,120 mm |
Rear overhang, upper carriage | 1,700 mm |
Swing radius, rear | 1,839 mm |
Swing radius, front (L2.5) | 1,990 mm |
Digging depth (L2.5) | 5,130 mm |
Reach (L2.5) | 9,045 mm |
Breakout force, bucket cylinder (ISO) | 106 kN |
Breakout force, dipper (ISO) | 70 kN |
Max. bucket size | 0.80 m³ |
Max. traction | 111 kN |
To contact Sydney Trucks & Machinery STM about MX17G Wheeled Excavator use Get a quote.
