Specifications:
- Total operating weight: 9600 - 10600 kg (21,164 - 23,369 lbs)
- Engine power: 55 kW (75 hp)
- Boom type: Mecalac boom
- Tail swing radius: 1385 mm (4'6'')
- Minimum full swing diameter: 2710 mm (8'9'')
- Turning circle: 4915 mm (16'1'')
- Travel speed: 25 kph (15.5 mph)
- Overall width: 2247 mm (7'4'')
- Bucket volumes: 0,08 - 0,75 m³ (0.10 - 1.0 yd³)
- + and - with forks: + 5000 mm / - 3700 mm (+16'5'' / -12’1”)
- Dumping height with a loading bucket: 4077 mm (13’4’’)
- Maximum reach: 7125 mm (23’4”)
To contact Mecalac about Wheeled Excavator 12MSX use Get a quote.
