Key Features

• NVIDIA Jetson AGX Xavier with 32 TOPs AI performance

• 4x M12 GbE with PoE, 1x lockable HDMI output, 4x USB 3.0

• 1x M.2 B-key for LTE/5G; 1x M.2 A/E key 2230 for Wi-Fi

• 2x CAN DB-9 CAN-FD from AGX module, with isolation

• Power with ignition control

• Nominal Voltage: 24VDC, 36VDC, 72VDC and 110VDC (EN50155 compliant)

Built on the latest industrial version of NVIDIA's Jetson AGX Xavier module, the AVA-RAGX provides a compact, rugged AI-enabled solution for both onboard and wayside railway applications that delivers uncompromised reliability and performance in harsh operating environments. The AVA-RAGX is a new addition to ADLINK’s railway AI-enabled Video Analytics (AVA) platform portfolio, the AVA-RAGX offers rail solution providers a high level of flexibility to select the configuration best suited to their application.

AI is accelerating the digital transformation of the railway industry to improve operational efficiency, deliver smarter and safer customer services, and create new business opportunities. ADLINK is at the forefront of AI computing solutions that help railway companies focus on differentiating and transforming their end applications.

The AVA-RAGX platform is ideal for real-time video and graphics analysis applications vital in today's increasingly complex railway operations. With an 8-core NVIDIA Carmel CPU and a 512-core NVIDIA Volta GPU, the platform exemplifies ADLINK's expertise in developing next-generation railway systems. Combining AI, machine learning, edge computing and IoT technologies and certified to EN 50155 specifications, the AVA-RAGX is a rugged, fanless and compact platform designed for flexible deployment in harsh operating environments.

With its compact 288 x 190 x 72 mm dimensions, the AVA-RAGX specifically targets space-restricted environments, making it ideal for edge-type railway applications with small solution enclosures. It provides a full complement of I/O ports, including four M12 Gigabit ports and wireless connectivity (5G/LTE & Wi-Fi), as well as four digital input and four output 24VDC-110VDC with 1.5kV isolation.

When integrated with an advanced camera system, radar, Lidar, GNSSC and AI software stack, the AVA-RAGX system can provide precise information about the train's surroundings and exact position. A challenge particular to the rail industry is the long braking distance of the train. The AVA RAGX can detect emerging hazards far ahead to increase warning time when connected to appropriate sensors. Also, the hazard detection system can improve operational efficiency and safety and helps prevent accidents, especially when trains run at night or in adverse weather conditions that reduce visibility.

When installed on an inspection train, the trackside equipment fault detection system processes images captured from wayside equipment, such as the pantograph and track, in real-time. Driven by NVIDIA's GPU accelerated computing, the system can effectively identify potential equipment faults at a train speed of up to 75mph (120km/h).

Incorporating AI-at-the-edge into onboard legacy IP camera networks enhances passenger travel conditions. The AVA-RAGX can perform checking for unattended luggage, seat occupancy, and passenger counting. When deployed in train station, the AVA-RAGX can analyze the real-time video stream received from station platforms to detect suspicious or aggressive human behaviors, crowd movement and even face mask-wearing.
