Rose Forgrove Minerva | HFFS - Horizontal Flow Wrappers

Name: Rose Forgrove Minerva | HFFS - Horizontal Flow Wrappers
Brand: Barry Wehmiller Australia

Supplier: Barry Wehmiller Australia

Rose Forgrove Minerva

17 Recent ViewsIn Stock

Features

Hygienic and easy-to-clean design suitable for a wide range of challenging industries
Sloped tops and rounded legs minimize debris build up
Versatility throughout a wide range of packaging applications
Icon-based operator interface with real time diagnostics
Straightforward and intuitive set up features for fast, repeatable changeovers
‘No product - no bag’ feature minimizes film waste
Misplaced product detect
Reel Low / Run-Out with Beacon
Easy film thread system for a quick change-over and reel replacement
Adjustable or fixed folding box
Options of standard chain infeed or range of multi-belt feeders

Versatility in Flow Wrapping
The Rose Forgrove Minerva is a horizontal flow wrapper packaging machine suitable for wrapping a large variety of food and non-food products with high speed capabilities and pre-arrangement for complete automation. The Rose Forgrove Minerva distinguishes itself through innovating engineering that focuses on delivering exceptional performance in challenging environments. It is a PLC controlled horizontal rotary form fill seal machine with five (5) independent motors and rotary sealing jaws.

Dependable and Flexible Machine Design

Solid mechanical construction with special attention to aspects of Hygiene (GMP), ease of Cleaning & Maintenance and Operator Ergonomics
Right and left hand machines available (right hand: product flows from left to right)
Machine finish in Stainless Steel or Mild Steel Painted
Single reel 650mm reel width / 350mm max reel diameter / 76mm diameter core
Film fed from the top or bottom of the machine
All parts in contact with products are stainless steel and food grade plastic

User-friendly Controls

Control system with industry standard Allen Bradley PLC
Operator Interface with TFT color touch screen 10”
Multi-axis drive technology with 5 independent axis for product infeed, longitudinal sealing rollers, film feed, rotary sealing head and discharge belt
No-product / no-bag system
Misplaced Product Detect
Individual temperature control circuits for the 2 set of heated longitudinal sealing rollers
Independent temperature control on the sealing jaws integrated into control panel
Automated product size change with all program parameters saved in product data base, holding parameters for up to 99 different products
6 x User defined electronic cam outputs for peripheral devices available
Service mode for diagnostics, trouble shooting and basic machine configuration, different level (User configurable) of password protection
Additional user-defined password level for limiting / excluding access to selected machine functions, setting changes and sensitive data
