Telescopic handler | MHT-X 790 | Mining TelehandlerGet latest price

The MHT-X 790 is a telescopic handler with a capacity of 9 tonnes and a maximum lifting height of 7 metres. It is equipped with a 145 hp engine and a hydrostatic transmission that makes the movements extremely precise. Thanks to the 4 driving and steering wheels, it is easy to manoeuvre on all types of terrain in complete safety. The MHT-X 790 telescopic handler is used in construction, quarries and industry. It can be equipped with a wide range of attachments: forks, positioner, hook and winch, shovel, man basket and tyre grippers, cylinders and tubes. For maximum comfort, this machine is equipped with a panoramic, ergonomic cab, Easy Step access, JSM joystick and colour touch-screen display.

Capacities

• Max. capacity

  • 9000 kg
• Load centre of gravity

  • 600 mm
• Max. lifting height

  • 6.80 m
• Max. outreach

  • 3.70 m

Weight and dimensions

• Overall length

  • 6.41 m
• Unladen weight (with forks)

  • 13160 kg
• Ground clearance

  • 0.44 m
• Wheelbase

  • 2.87 mm
• Length to face of forks

  • 5.21 m
• Overall width

  • 2.47 m
• Overall height

  • 2.50 m
• Overall cab width

  • 0.93 m
• Tilt-down angle

  • 125 °
• Tilt-up angle

  • 12 °
• External turning radius (over tyres)

  • 4.89 m
• Forks length / width / section

  • 1200 mm x 200 mm / 60 mm

Wheels

• Standard tyres

  • 445/65 R22,5
• Number of front wheels / rear wheels

  • 2 / 2
• Drive wheels (front / rear)

  • 2 / 2
• Steering mode

  • 2 wheel steer, 4 wheel steer, Crab mode

Engine

• Engine brand

  • Yanmar
• Engine norm

  • Stage IIIA
• Engine model

  • 4TN107HT-5SMUF
• Number of cylinders / Capacity of cylinders

  • 4 - 4567 cm³
• I.C. Engine power rating / Power (kW)

  • 143 Hp / 105 kW
• Max. torque / Engine rotation

  • 602 Nm@1500 rpm
• Engine cooling system

  • Water
• Battery / Batteries capacity

  • 12 V / 180 Ah

Transmission

• Transmission type

  • Hydrostatic
• Number of gears (forward / reverse)

  • 2 / 2
• Max. travel speed

  • 35 km/h
• Parking brake

  • Automatic negative parking brake
• Service brake

  • Oil-immersed multi-discs braking on front & rear axles

Hydraulics

• Hydraulic pump type

  • Load sensing pump
• Hydraulic flow - Pressure

  • 185 l/min - 270 bar

Tank capacities

• Engine oil

  • 13 l
• Hydraulic oil

  • 151 l
• Fuel tank

  • 165 l

Miscellaneous

• Safety cab homologation

  • ROPS - FOPS cab (level 2)
• Controls

  • JSM
