Walk Behind Trencher | TRX26Get latest price

It works faster and straighter than you would expect from a walk-behind trencher. The track drive design provides a low centre of gravity and a large light footprint, offering stability and increased maneuverability – without causing damage to existing turf. The TRX26 walk-behind trencher also makes valve box installation a snap with its ability to cross-trench without damaging trench sidewalls.

Features

• 26 HP Kawasaki® V-Twin engine
• 34 inch width allow easy access through standard 91 cm (3 foot) gates
• Three-pump 32.5 gpm combined hydraulic flow for maximum digging efficiency
• Easy-to-use TX-style traction control system
• Dual Element Air Cleaner reduces engine wear
• Trencher Boom – depths up to 48 inch
• TRX26 accessories: Boring Unit, Backfill Blade and Crumber

Technical Data

• Model #: 22974
• Engine: 26hp Kawasaki FX730V, 4 cycle air cooled
• Fuel Tank:  18.2 litres
• Oil Capacity
  • 2.1 litres (1.9 Imperial quarts) with oil filter change
  • 1.8 litres (1.6 Imperial quarts) without oil filter change
• Start Method: Solenoid shift type electric starter motor
• Gear Pump: A single section 53.0 lpm (11.7 gpm) gear pump powers the lift and trencher hydraulic systems
• Hydrostatic Drive
  • The traction circuit is powered by independent, belt driven hydrostatic in dual closed loop systems. The pumps are Hydro-gear PG pumps and have service bypass valves for towing. The pumps are mechanically actuated by the patented Toro TX traction control system, utilizing on-pump neutral centering systems.
• Battery
  • 12 volt, BCI group U1 battery with 300 CCA powers the electrical system
• Electrical Interlocks
  • Switches are installed on the machine to ensure the following requirements:
    • – To start the machine, the auxiliary hydraulic valve must be in neutral
    • – To start the machine, the traction control must be in neutral
    • – If the parking brake is ON, the engine will cut out when the attempt is made to drive the machine
• Engine Controls
  • Panel mounted, including the ignition, throttle and choke. The throttle and choke are remote lever/cable operated
• Steering
  • Toro TX patented control system
• Auxiliary
  • A two-step, spring return (operator presence) lever connects to the trencher spool on the control valve and actuates the spool for the trencher motor
• Headshaft Speed
  • 210 rpm w/ 554 ft/lbs of torque
• Track
  • 5.9 inches (15.0 cm) wide-endless nylon reinforced rubber track
• Dimensions
  • Sprocket-drive; 3 road wheels per side. Traction dual hydrostatic pump
• Weight
  • 566 kg (1,248 lbs)
• Performance
  • Trench Depth (max)
  • 2 Foot Boom – 61.0 cm (24.0 inches)
  • 3 Foot Boom – 91.0 cm (36.0 inches)
  • 4 Foot Boom – 122.0 cm (48.0 inches)
  • Trenching Angle: 0-65 degrees
  • Trench Width: 10.0 – 15.0 cm (4.0 – 8.0 inches)
  • Auger Diameter: 31.8 cm (12.5 inches)
  • Auger Length: 32.54 cm (12.81 inches), 41.4 cm (16.3 inches) from centre of chain
  • Auger Speed: 226 rpm (95% efficiency)
  • Torque: Approximately 427.1 Nm (315 ft-lbs) at 172.4 bar (2900 psi) – 95% efficiency
  • Ground Speeds: Forward: 0-5.3 km/h, Reverse: 0-1.7 km/h
  • Ground Pressure: 28.3 kPa (4.1 psi), 29.7 kPa (4.3 psi) with 3 foot boom
• Chain Types
  • -pitch chain with 4-pitch soil-cup tooth
  • 2-pitch combo Chains (rock and soil)
  • 2-pitch “Shark” welded rock tooth
• Warranty
  • Standard warranty period of 2 years or 1000 hours limited warranty.
