Specifications
Model | KXS7522AWCLE |
X-ray output | Tube voltage 30 to 80 kV, tube current 0.4 to 3.3 mA, output 12 to 100 W |
Safety | X-ray leakage maximum 1.0 µSv/h or less, prevention of x-ray leakage by safety devices |
Display | 15-inch color TFT LCD |
Operation method | Touch panel (with touch buzzer) |
Product size 1, 2 | Maximum width 240 mm, maximum height 120 mm |
Belt width | 270 mm |
Preset memory | 200 |
Belt speed 3 /Maximum product weight 4 | 10 to 60 m/min maximum 5 kg |
60 to 90 m/min maximum 2 kg | |
0 to 40 m/min maximum 10 kg (optional) | |
Power requirements 5 | 100 to 240 AC, single phase, 50/60Hz?700 VA or less (standard) |
Mass 6 | 225 kg |
Environmental conditions 7 | Temperature: 0°C to 35°C, Relative humidity: 30% to 85%, non-condensing |
Protection class | Conveyor IP66, other parts IP40 |
Exterior | Stainless steel (SUS304) |
To contact J.L.Lennard about X-Ray Food Inspection System | XR75 Standard use Get a quote.
