Industrial Rackmount Router | CCR1016-12S-1S+Price Guide:$1,248Get latest price

The CCR1016-12S-1S+ from MikroTik is an industrial-grade cloud router powered by a sixteen core 1.2GHz processor and 2GB RAM. This CCR1016 model comes in a 1U rackmount enclosure with dual power supplies and features (12) SFP ports, (1) SFP+ port (supports only 10G SFP+ modules), (1) microSD card slot, (1) microUSB type AB port, (1) RS232 Serial port, and an LCD panel for easy configuration.

The MikroTik cloud core router series is powered by RouterOS, a full-featured routing operating system with features such as dynamic routing, hotspot, firewall, MPLS, VPN, advanced quality of service, load balancing and bonding, real-time configuration, monitoring, and more. This product comes with a Level 6 RouterOS license.

Note: This product does not include fibre modules. If you need SFP transceivers, select an option from the drop down menu or make sure to add them to your cart separately.

Specifications

• Product code: CCR1016-12S-1S+
• CPU nominal frequency: 1.2 GHz
• CPU core count: 16
• Size of RAM: 2 GB
• Architecture: TILE
• 10/100 Ethernet ports: None
• 10/100/1000 Ethernet ports: None
• MiniPCI slots: 0
• MiniPCI-e slots: 0
• Number of USB ports: 1
• Power Jack: 2x IEC C14
• 802.3af support: No
• PoE: No
• Voltage Monitor: Yes
• PCB temperature monitor: No
• CPU temperature monitor: Yes
• Operating System RouterOS: v6
• Operating temperature range: Max ambient temperature 50° @ 1.2GHz; 70° @ 1GHz CPU core frequency
• License level: L6
• Current Monitor: Yes
• CPU: TLR4-01680CG-12CE-A3
• Max Power consumption: 44W (with loaded SFP)
• SFP ports: 12
• SFP+ ports: 1
• USB slot type: microUSB type AB
