Industrial Wood Chipper | Model 4200AFEGet latest price

Whether the job is rural utility maintenance, residential tree work or council parks maintenance, the 4200 series is our all-rounder solution to address most of your chipping needs. With a gross weight under 2,000kg it’s easily towable by most standard ute’s and small car license trucks. Equipped with a reliable Perkins engine and Parker hydraulics, the feed rollers are controlled by our unique Tomcat reversing auto-feed control (TRAC) and a powerful hydraulic ram that provides crush capability to feed the most stubborn side branches.

Additional 4200AFE features include curb side mounted controls providing a more convenient location for operators, a side-load anvil, a 360-degree manual swivel discharge chute which offers multiple locking positions for greater operator control over chip discharge, and a three-position control bar with dual safety e-stops and bump bar, further elevating industry safety standards.

Mounted on the industry’s leading trailer configuration, including a spare wheel, toolbox and cone spike, with rake holders and pole saw mount standard option on the unit.

SERIES FEATURES:

• 9″ Chipping capacity
• 50Hp Perkins diesel engine
• Hydraulic lift & crush
• 7” over centre clutch
• 360° adjustable discharge chute
• Large toolbox & spare wheel
• Parker hydraulics
• Electric braked trailer
• In-feed : 220mm x 260mm
• Parts locally available over the counter
• Tomcat reversing auto-feed control (TRAC)
• Sealed Bearings

SPECIFICATIONS

• Engine: 50Hp PERKINS Diesel
• Chipper capacity: 230mm
• Infeed opening: 230mm x 270mm
• Feed hopper 1250mm x 750mm
• Twin hydraulic in-feed rollers
• Independent hydraulic lift & crush
• Feed rate: 10-30 Meters per minute
• Cutting system: Drum with 2 x double sided blades
• Safety: Twin e-stops, bump bar, forward/reverse bar, curb side controls
• Drum Shaft Diameter: 70mm
• Hydraulic Tank: 80L
• Fuel Tank: 80L
• Length: 5.4m
• Width: 1.9m
• Height: 2.3m
• Weight: 1650kg
• Tyres: 15“ light truck
