Large Excavators | SY135CGet latest price

The SANY SY135C sets a new benchmark in the 13–15 tonne large excavator class, delivering an exceptional balance of power, control, and efficiency. Designed for precision and reliability in infrastructure, civil, and general construction, it combines a reinforced boom and arm, a heavy-duty undercarriage, and advanced load-sensing hydraulics to ensure smooth, consistent performance in every application.

Powered by the Isuzu 4JJ1X Stage V engine, the SY135C delivers superior fuel economy, low emissions, and consistent high torque output across diverse operating conditions. The robust dozer blade and stable track platform provide outstanding digging force and lifting stability, even in demanding terrain. Equipped with a broad range of standard and optional configurations, the SY135C is engineered to maximise versatility and productivity on any job site.

Key Features

• Rear camera
• 2 proportional auxiliary lines as standard
• High-resolution 7“ touch display
• Hydraulic quick-coupler line system
• Heavy-duty undercarriage

General Information

• Weight

14870 kg

• Standard bucket capacity

0.6 m³

• Transport length

7700 mm

• Transport width

2590 mm

• Height over cabin/ROPS

2820 mm

• Engine

ISUZU GJ-4JJ1XKSC

• Rated Power

73 kW

• Engine Revolutions

2000 rpm

• Emission Stage

III

• Max. digging depth

5500 mm

• Max. digging reach

8,270 mm

• Min. Swing radius

2,410 mm

• Bucket digging force (ISO)

92.7 kN

• Arm digging force (ISO)

67 kN

• Max. oilflow

2x110 l/min
