Large Excavators | SY500HGet latest price

HIGH PERFORMANCE INCLUDED

Thanks to its perfect balance of power and precision, it is the ideal workhorse on cost-oriented construction sites, ensuring that extensive earthworks can be carried out cost-effectively in a short time. In addition, it is perfectly equipped for demanding use in harsh environments, with a stable undercarriage, high stability of all components and a powerful drive.

Key Features

• Comfortable driver‘s cab
• Total safety package, including camera
• Air-suspension driver‘s seat
• Powerful, large-volume engine

General Information

• Weight

52500 kg

• Standard bucket capacity

3.1 m³

• Transport length

12103 mm

• Transport width

3596 mm

• Height over cabin/ROPS

3874 mm

• Engine

Cummins QSX12

• Rated Power

298 kW

• Engine Revolutions

2100 rpm

• Emission Stage

V

• Max. digging depth

7705 mm

• Max. digging reach

10929 mm

• Min. Swing radius

5216 mm

• Bucket digging force (ISO)

253 kN

• Arm digging force (ISO)

227 kN

• Max. oilflow

2x360 l/min
