Rotary Cutters | 5026Price Guide:$86,500Get latest price

5026 Features:

• Get the job done fast with over 26' of cutting width.
• 1000 RPM drive line with heavy duty slip clutches and 80° constant velocity u-joint.
• 2-piece replaceable skid shoes on wings.
• 10 gauge deck with deck protection rings.
• 6 or 8 7.00 x 15 light truck tyres.
• Hydraulic phasing cylinders for level lift.
• Double acting wing lift cylinders with mechanical float.
• 50° splitter box keeps drive lines short and machine more compact.
• An optional fixed shredding blade kit is available for enhanced shredding.
• Spring steel bushings at all major pivot points.
• Suspension for centre and wing frames.
• Round skid pans on standard unit.

5026 Specifications:

• Cutting width: 7.98 m (26’ 2”)
• Overall width: 8.15 m (26’ 9”)
• Overall length: 5.13 m (17” 1”)
• Cutting height: 25 mm - 356 mm (1" - 14")
• Overall transport width: 2.98 m (9’ 9”)
• Overall transport height: 3.76m (12’ 4”)
• Shipping weight, wet: 3583 kg (7900 lbs.)
• Hitch weight, transport: 1089 kg (2400 lbs.)
• Cutting capacity: 51 mm (2") diameter material
• Minimum tractor HP: 120 HP (90 kW)
• Tractor hydraulics: 2 double acting circ, 1750 PSI (12 MPA)
• Wing outer: 974 RPM-15,300 ft/min (280 km/hr)
• Wing inner: 812 RPM-15,300 ft/min (280 km/hr)
• Centre: 800 RPM-15,079 ft/min (276 km/hr)
• Working Range of Wings: 15° down to 45° up
• Blade overlap:152 mm (6") centre to wing, 127 mm (5”) inside to outside wing
