Rotary Cutters | XH1500Price Guide:$54,000Get latest price

XH-1500 Features:

• Extra heavy duty, high horsepower Bondioli & Pavesi gearboxes with oil level sight glass and 4.45 mm (1 3/4") input shafts and 75mm (3”) output shafts, 260 HP divider, 210 HP centre & wings.
• Bondioli & Pavesi G8 drive lines with high-torque wing clutches give better performance in rough cutting.
• A deep cutting chamber coupled with high blade tip speeds result in a superior cut & unsurpassed material flow.
• Optional mulching blades and Schulte's exclusive fixed knife system available.
• 610mm (24") severe duty tyres, transport height of 444mm (17 1/2") along with superior performance in wet conditions.
• Lower pressure 200mm (8") stroke hydraulic phasing cylinders for a level lift for an even cut.
• Low maintenance constant velocity tractor shaft requires weekly, rather than daily service.
• Centre suspension reduces stress on tractor drawbar.
• 10mm (3/8”) thick formed deck protection rings prevent blade to deck contact.
• Double safety chains with individually replaceable links are standard equipment.
• Single domed, sweep clean deck design eliminates excess weight over competitive double deck designs, eliminates build-up of debris & prevents rusting on top side of deck.
• Tandem walking axles result in smooth operation over rough surfaces.
• 35mm (1/4”) thick stump jumpers with Pentagon Blade Bolt design allow cutter sections to ride over obstructions.
• Replaceable spring steel bushings in the hitch pivots, main pivots, tension link pivots, suspension pivots and the centre and outside wheel standard main pivots.
• Increased blade tip speeds and greater space under the deck contribute to clean cutting in all conditions.
• The centre suspension system reduces stress to the rotary cutter and the tractor.
• Industry leading transport clearance improves performance in rough terrain.

XH-1500 Specifications:

• Cutting Width: 4.57m (15’)
• Overall Width: 4.83m (15’10”)
• Overall Length: 4.88m (16’)
• Transport Width min: 2.24m (7’ 4”)
• Transport Height: 2.24m (7’ 4”)
• Deck Thickness: 7 GA (3/16", 4.6mm)
• Weight approx.: 2636kg (5800 lbs)
• Hitch Weight, approx.: 864kg (1900 lbs)
• Minimum Tractor HP: 65 HP (52 kW)
• Recommended Tractor HP: 85 HP (67 kW)
• Cutting Height: 38 - 144mm (1.5 - 17.5")
• Ground Clearance :444mm (17.5")
• Cutting Capacity: 102mm (4") diameter material
• Blade Overlap: 165mm (6.5")
• Divider Gearbox Rating: 260 HP (194 kW)
• Centre & Wing Gearbox Rating: 225 HP (168 kW)
• Blade Tip Speed - 540 RPM
• Centre: 848 RPM, 4874m/min (15,493 ft/min)
• Wing: 986 RPM, 4722m/min (15,991 ft/min)
• Blade Tip Speed - 1000 RPM
• Centre: 850 RPM, 4884m/min (15,743 ft/min)
• Wing: 1002 RPM, 4798m/min (16,022 ft/min)
• Wing Working Range: 25° down to 90° up
