Rotary Cutters | FX-742Price Guide:$162,000Get latest price

FX-742 Features:

• 42' (12.8 m) of cutting width will make those long days short again. Use one cutter where traditionally two or three cutters were needed. Cover more ground, while reducing the number of tractors and fuel required in an operation. Increasing your efficiencies means more money in your pocket.
• Available with stump jumpers for pasture and grass maintenance or with Schulte's exclusive fixed knife and baffle technology for mulching crop residue such as straw, corn or cotton stalks.
• Unmatched reliability with a premium Bondioli & Pavesi SFT drive & gearbox system. 350 HP divider box, 180 HP T-boxes & 190 HP right angle down boxes.
• Size 10 main CV with an over running clutch provides worry free shut downs.
• Fully compatible for all row crop cutting in 30", 32", 38", 40" and one metre row spacing.
• A parallel solid tongue hitch maintains even load on the tractor draw bar.
• Full rubber grommet suspension across the entire unit reduces shock loading and maintains even cutting, even in the roughest of conditions.
• Schulte's unique driveline arrangement allows for independent clutch protection for each down rotor.
• A continuously welded 10-gauge domed deck adds strength and durability while reducing debris and water build up on the top of the deck.

FX-742 Specifications:

• Cutting width: 12.8 m (42’)
• Overall width: 13.1 m (42’ 11”)
• Overall length: 7.4 m (24’ 3”)
• Cutting height: 51 mm - 406 mm (2" - 16")
• Transport width: 3 m (9’ 10")
• Row crop wheel trans. width: 3.7 m (12’ 2")
• Transport height: 4.2 m (13’ 9”)
• Weight: 8165 kg (18,000lbs) depending upon configuration
• Hitch weight: 2950 kg (6,500lbs) depending upon configuration
• Cutting capacity: 51 mm (2")
• Minimum tractor size: 250 HP (186 kW)
• Blade tip speed: 4,970 m/min (16,300 ft/min)
• Blade overlap: 165 mm (6.5")
• Divider box rating: 350 HP (261 kW)
• T-box ratings: 180 HP (134 kW)
• Down box ratings: 190 HP (142 kW)
• Skirt thickness: 6.4 mm (1/4")
• Inside wing operating range: 11° down to 13° up
• Outside wing operating range: 8° down to 10° up
