Thermal Machine Vision Camera | A615

Name: Thermal Machine Vision Camera | A615
Brand: Teledyne FLIR

Supplier: Teledyne FLIR

The FLIR A615 is an easy-to-control, affordable, and compact thermal imaging camera for condition monitoring, process control/quality assurance, and fire prevention.

64 Recent ViewsIn Stock

The FLIR A615 can be fully controlled by a PC, and is Plug and Play with third-party machine vision software such as National Instruments, Cognex, Matrox, MVtec, and Stemmer Imaging.

The FLIR A615 produces high quality, 307,200 pixel infrared images with embedded temperature readings, so you can measure any point within the scene up to 2000°C.

EXCELLENT IMAGE QUALITY

The FLIR A615 features a 640 x 480 pixel microbolometer that detects temperature differences as small as 50 mK, for accuracy at longer distances.

16-BIT TEMPERATURE LINEAR OUTPUT

Measure temperatures in non-contact mode using any third-party software thanks to 16-bit temperature linear output.

HIGH-FREQUENCY STREAMING

Stream full-frame 16-bit images at 50 Hz, or in windowed mode as high as 200 Hz, for high-speed processes.

SPECIFICATIONS
OVERVIEW
Focal Length	41.3 mm
Housing material	Aluminium
IR Resolution	640 × 480 pixels
Packaging Size	360 x 180 x 550 mm
Contents	Hard transport case or cardboard box, Thermal imaging camera with lens, Utility CD-ROM, Calibration certificate, Ethernet™ cable, USB cable (FLIR A615), Mains cable, Power cable (pig-tailed), Power supply, Printed Getting Started Guide, Printed Important Information Guide, User documentation CD-ROM, Warranty extension card or Registration card, 6-pole screw terminal (mounted on camera)
