Nitro 7420 Self-Propelled Sprayer

Name: Nitro 7420 Self-Propelled Sprayer
Brand: New Holland Agriculture

1/6

Nitro 7420 Self-Propelled Sprayer

The Miller Nitro 7420 self-propelled sprayer features a front-mount boom, SprayView cab and industry-leading clearance, with 6100 L standard and 8000 L optional product tanks.

Front-mount boom and SprayView™ cabin provide superior visibility, keeping every nozzle in sight for instant adjustments and a clean spray pattern as conditions change.
Miller Intelligence and fuel savings.
Un-matched stability and manoeuvrability, with 50: 50 weight distribution.
Industry-leading clearance.
Quiet, operator-first cabin, balanced weight and settled suspension provide a planted ride that protects crop and boom in rough country.
Composed at working speed and agile at headlands, with less fatigue and better accuracy through long shifts.
Capacity to cover more hectares per day when spray windows are tight.
Easy access to daily service checkpoints and smart plumbing for faster loading and clean-out.
Choice of boom and application technology, integration with existing screens and connected data for quicker decisions.

Specification	Value
BOOM WIDTH	41.15 m (135ft)
Horsepower	373 (rated) / 434 (peak) hp
Fuel Tank	568 L
Cooling System	Efficient Single Pass stacked top to bottom, Hydraulically driven variable speed fan with reverse capabilities.
Alternator / Batteries	330 amp / 2 heavy duty – 1000 cca batteries
Transmission	Torq-Trac Hydrostatic Drive /Single Danfoss 250cc H1 drive pump
Final Drives	Danfoss H1 Series 110 cc Bi-Directional Drive Motors with Dana Spicer® CO 26 Torque Hubs
Travel speed	0 – 51 kph
Steering	Hydraulic with 2 steering cylinders
Suspension	4 wheel independent, auto level for each leg
Product Tank Options	6100 L (Standard) 8000 L (Optional)
Rinse system	6100 L - 568 L poly tank with quick fill. Electric standard / Auto Rinse optional 8000 L 668 L poly tank with quick fill. Electric standard / Auto Rinse optional
Crop Clearance	Up to 200 cm (tyre dependant)

IntelliSpray II for individual-nozzle control and precise rates.
Spray-Air for deep canopy coverage with lower water volumes.
Batching vessels, fast-fill, auto-grease, crop dividers and spray pattern lights.
Connection to a preferred field computer for seamless guidance and rate control.
