Mobile Wood Chipper | TP 130

Name: Mobile Wood Chipper | TP 130
Brand: Chipstar Australia

Supplier: Chipstar Australia

1/6

Mobile Wood Chipper | TP 130

12 Recent ViewsIn Stock

Suitability

Suitable for businesses or professionals that require a hook-up-and-go-portability in their mobile chipper. The TP130 can process 130mm branches and trees outputting uniform 8mm chips.

Features

25hp Kohler engine
road ready trailer
hydraulically fed disc chipper
Two anvils in Raex 400
adjustable ejector spout
consistent 8mm chip output

Usability

Lindanna is Europe’s leading chipper because its range is designed with the end-user in mind. This is not only user-friendly, it’s great value for money.

Technical Data
Max Wood Diameter	130mm
Max Opening	H x W = 130 x 220mm
Operation	Return/forward/stop of feed rollers through operating bar (yellow)
Chipper Principle	Disc
Cutting Angle	90 degrees
Hopper Placement	Parallel
Feed Rollers	Horizontal hydraulic feed roller
Rotordisc – Diameter	660mm
Rotordisc – Weight	85kg
Number of Knives	2pcs.
Chip Size	8-10mm
Anvil/Counter Steel	1 Horizontal and 1 Vertical
Stress Control System	TP PILOT Including hour counter
Engine	18 kw 25hp Kohler
Fuel Consumption	5 litre/hour
Fuel Tank Size	24 litres
Chip Capacity	4-5 m³/hour (Experience numbers by manual operation)
Weight	660 kg
Tool Kit	Yes
Trailer	Galvanized with draw bar and brakes

Extra Equipment
Extended Ejector Spout	500 mm vertical â€¢ 335 mm vertical â€¢ 1,000 mm horizontal
Silverbreakers	Type A or B – are used if extra requirements for chip quality is needed
Light Bar	Light bar with complete set of rear lights
